Amplificator monobloc Jbl cu puterea de 600w RMS la 4 ohm si 1200 w RMS la 2ohm
Spend 200,00 lei more and get Free Shipping!
Transport gratuit pentru comenzi mai mari de 200 ron
 |
302.09 Lei x 4 rate |
Install
- Terminal Layout: Two-Sided
- Screw Mount / Wire Cover: Integrated Wire and Mounting Screw Terminals
General
- Amplifier Type: Class-D (Digital)
- Channel Design: 1 Channel (Mono)
- Power Supply Design: DC-DC PWM Power Supply
- Power Supply: MOSFET
- Pre-Amp Stage: Discrete
- Final Outputs: Power MOSFET
- Crossover: Variable Lowpass Filter
- Gain Control: Continuously Adjustable Gain Control
- Bass EQ: Bass EQ Function
- Bass Control: Remote Bass Control (RUX-KNOB) included
- Remote Turn On: Remote Sensing Function (for Speaker Level Input)
- Low-impedance Possibility:
- Current Protection: Over-Current, Over-Voltage, Under-Voltage and Thermal Protection
- Board Circuitry: S.T.A.R. Circuit
- RCA Output: Non-Fading Pre-Amp Output (4 Volts)
- Speaker-Level Inputs: 4-channel Speaker Level Inputs
- Power Indicator: Top Mounted Blue LED Power Indicator
- Thermal Control: Multi-stage Power Limits
SPECIFICATIONS
Max Power Output Ratings
- Total Max Power: 2000W
RMS Power Ratings
- Per channel into 4 Ohms: 600W RMS x 1 (14.4V at <1% THD+N)
- Per channel into 2 Ohms: 1200W RMS x 1 (14.4V at <1% THD+N)
Sound Tuning
- Crossover Frequency (LPF): 50 - 400 Hz, -24dB/oct.
- EQ (Equalizer): 0 to +12dB, fc=50Hz
Dimensions
- Foot Print (WxHxD) mm: 342 x 55 x 219 mm
- Heat Sink (WxHxD) mm: 305 x 55 x 215 mm
General
- Power Requirements: 14.4 V.DC (11-16V allowable)
- Input Sensitivity (RCA Input): 0.15 - 4.0 V
- Input Sensitivity (Speaker Level Input): 0.4 - 10 V
- Input Impedance: >10k ohms
- Frequency Response (+0, -3dB: 1W into 4 Ohms) for Subwoofer: 10 -400 Hz
- THD+N (10W into 4 Ohms): ≤ 1 %
- THD+N (10W into 2 Ohms): ≤ 1 %
- THD+N (Rated Power into 4 Ohms): ≤ 1 %
- THD+N (Rated Power into 2 Ohms): ≤ 1 %
- Damping Factor (10W into 4 Ohms at 100Hz): >750
- Signal to Noise (1W into 4 Ohms): >85 dB
- Signal to Noise (Rated Power into 4 Ohms): >107 dB
- Preamp Output: 4.0V Max.
- Remote Level: -20 to 0 dB
- Weight: 4.16 kg
| Numar de canale | 1 canal |
Alpine este leaderul producatorilor de echipament audio, componente multimedia si sisteme de navigatie pentru autoturisme
